Yamaha DBR12 12-Inch Powered Loudspeaker

The Yamaha DBR12 12-Inch Powered Loudspeaker is a 2-way bi-amplified speaker designed for live sound, DJ setups, stage monitoring, public speaking, rehearsals, and performance venues. With its 12-inch low-frequency driver, high-output amplifier system, and bass-reflex cabinet design, it delivers clear projection and full-range sound for professional audio applications.

Built with Yamaha DSP technology, FIR-X tuning, D-CONTOUR processing, and a 1000 W dynamic power amplifier, the Yamaha DBR12 provides powerful sound performance in a portable cabinet design. Its side handles, pole socket, flexible input connections, and monitor-friendly design make it suitable for front-of-house sound, floor monitoring, and portable PA setups.

Key Features

• 12-inch 2-way powered loudspeaker from Yamaha’s DBR Series
• Bi-amplified bass-reflex speaker design for full-range sound reinforcement
• 1000 W dynamic output power for live audio applications
• 12-inch cone low-frequency driver with 2-inch voice coil
• 1.4-inch high-frequency compression driver with 1-inch throat
• Maximum output level of 131 dB SPL for strong sound projection
• 52 Hz - 20 kHz frequency range for balanced full-range performance
• FIR-X tuning with linear phase FIR filter for smooth crossover performance
• D-CONTOUR processing with FOH/MAIN, MONITOR, and OFF modes
• 90° horizontal and 60° vertical coverage for wide sound dispersion
• Combo input connectors and RCA input options for flexible source connection
• XLR output with CH1 parallel through or CH1 + CH2 mix function
• Fan cooling system with 4-speed operation
• Durable plastic cabinet with black finish
• Side handles for easier transport and setup
• 35 mm pole socket for speaker stand mounting
• Mounting points compatible with M8 eyebolts for installation use

Specifications

Brand	Yamaha
Model	DBR12
Series	DBR Series
Product Type	Powered Loudspeaker
Speaker Type	2-Way, Bi-Amp Powered Speaker, Bass-Reflex Type
Frequency Range	52 Hz - 20 kHz
Nominal Coverage	90° Horizontal, 60° Vertical
LF Driver	12" Cone, 2" Voice Coil, Ferrite Magnet
HF Driver	1.4" Diaphragm, 1" Throat Compression Driver, Ferrite Magnet
Crossover	2.1 kHz with FIR-X Tuning
Output Power	Dynamic: 1000 W, Continuous: 465 W
Dynamic Power Distribution	LF: 800 W, HF: 200 W
Continuous Power Distribution	LF: 400 W, HF: 65 W
Maximum Output Level	131 dB SPL
Input Connectors	INPUT 1: Combo x 1, INPUT 2: Combo x 1 + RCA Pin x 2
Output Connector	XLR3-32 x 1
Output Function	CH1 Parallel Through or CH1 + CH2 Mix
Processor	D-CONTOUR: FOH/MAIN, MONITOR, OFF
Cooling System	Fan Cooling, 4 Speeds
Power Requirements	100 V, 100-120 V, 220-240 V, 50/60 Hz depending on region
Power Consumption	74 W at 1/8 Power, 18 W Idle
Cabinet Material	Plastic
Finish	Black
Handles	Side x 2
Pole Socket	35 mm Bottom Pole Socket x 1
Flying and Mounting Hardware	Bottom x 2, Rear x 1, Compatible with M8 x 15 mm Eyebolts
Dimensions	Height: 60.1 cm, Length: 34.8 cm, Width: 37.6 cm
Net Weight	15.8 kg

Why Choose Yamaha DBR12?

• Designed for users who need a powerful 12-inch active loudspeaker for live sound applications
• High output level supports clear projection for performances, events, and PA setups
• D-CONTOUR processing allows the speaker response to be adjusted for main speaker or monitor use
• Flexible input and output connections support microphones, mixers, playback devices, and linked speaker setups
• Portable cabinet design with side handles and pole mounting support makes setup easier in different environments

Portable Power for Live Sound

The Yamaha DBR12 12-Inch Powered Loudspeaker combines strong output, practical connectivity, Yamaha DSP processing, and a portable cabinet design. With its 12-inch woofer, 1000 W dynamic amplifier system, wide coverage, and flexible mounting options, it is well suited for live music, DJ events, public address setups, rehearsals, and professional sound reinforcement applications.
